HumiSeal® 1A27 is a single component, polyurethane conformal coating, suitable for general printed circuit board applications. HumiSeal® 1A27 contains no free isocyanates. HumiSeal® 1A27 coating is RoHS Directive 2002/95/EC compliant and recognized under UL File Number E105698.
Overview
HumiSeal® 1A27 is a single component, polyurethane conformal coating, suitable for general printed circuit board applications. HumiSeal® 1A27 contains no free isocyanates. HumiSeal® 1A27 coating is RoHS Directive 2002/95/EC compliant and recognized under UL File Number E105698.
Overview
Specifications
| Curing Conditions | Heat |
|---|---|
| Recommended Thickness | 25 - 75 microns |
| Quantity per Package | 12 Cans |
| Cure Time | 30 days at RT / 30 hours @ 76°C / 20 hours @ 88°C |
| Chemistry | Urethane |
| Solids Content % | 6.1 ± 1 % |
| Material | 30 days at RT / 30 hours @ 76°C / 20 hours @ 88°C |
| Drying Time | 16 minutes |
| Packaging | CASE |
| Volatile Organic Compounds | 476 g/l |
Downloads
1A27 Aerosol Technical Data Sheet
pdfDownload
